Subbase system for the installation of sports surfacing and artificial turf
Sports fields built with traditional concrete or asphalt are now outdated. They are expensive, require installation times, and have a significant environmental impact.
Our modular polymer panels provide excellent stability, unmatched drainage capacity, and outstanding playability. They are designed to significantly improve safety and performance for athletes and other users. Thanks to their quick and simple installation using an easy-click system, both economic and environmental impact are greatly reduced.
They are the perfect base for any type of application on hard ground surfaces for artificial turf or other paved surfaces, suitable for both indoor and outdoor use.
MATERIAL:
- Post-industrial recycled material
- Limited UV protection
SPECIFICATIONS:
- Dimensions: 753 × 566 × 22 mm (1 panel = 0.426 m²)
- Weight: 1.93 kg per panel – 4.55 kg/m²
- Structure: Hexagonal cell design
- Anti-slip system: Minimum 571 support feet per panel
- Interlocking system: Click-lock system
TEST:
- GMAX: 137
- Load capacity: 374 psi vertical load, up to 998 psi
- Structure: Hexagonal cell design
- Vertical drainage: 1,600 in/hr (40,180 mm/hr)
- Horizontal drainage: 130 in/hr (3,600 mm/hr
- Water storage capacity: 7.5 L per panel
- Thermal expansion: 2.4 mm above 60°C
- Slip resistance: Twice the slip resistance of stabilized aggregate
PLAY HARD. PLAY SAFE. PLAY JOKER FLOORS.
